Features:
1. Energy saving, Eco-friendly.
2. Modularization design, smaller size, less weight, convenient to install and maintain.
3. Higher power rating , lower heating, fast and stable running.
4.Two poles structure designs, shorter circuits, higher power efficiency.
5.Parallelled with any related channels, higher using efficiency.
6.Current loop and constant voltage loop are both running together on the hardware, control
over current and over voltage as well, enable the safety protection to work all time during testing
7.Accuracy range according to the module, ensure the accuracy of heavy current equipment.
8.Hardware output purely with fast response,high running speed and smaller ripple wave
9.Multiple protections for equiment running safty with hardware and software.
10.Support the simulation of battery work condition.
11. Linux software keep the system more safe and stable.
12.Support off -line running keeps the data more safety.
| Contents | Parameter | |
| Channels | 4CH | |
| Current | 300A | |
| Current Accuracy | ±0.05%FS | |
| Voltage | 0V~100V | |
| Voltage Accuracy | ±0.05%FS | |
| Mini record time | 10ms | |
| Energy efficiency | Charging:>85% , ,Discharging:>80% | |
| Stability | <0.5%FS | |
| Type of Cooling | Fan forced cooling | |
| Control module | Individual control | |
| Cycle quantity | Unlimited | |
| Safety protection | Support over voltage ,under voltage, capacity,
over current, lower current, over temperature protection. |
|
| No. | Contents | Item No. | Voltage(V) | Current(Amp) | Channels |
| 40 | 200V Series
|
BT200V50A-T | 20V～200V | 0～50A | 4 |
| 41 | BT200V100A-T | 20V～200V | 0～100A | 4 | |
| 42 | BT200V200A-T | 20V～200V | 0～200A | 2 | |
| 43 | BT200V400A-T | 20V～200V | 0～400A | 1 | |
| 44 |
500V Series
|
BT500V100A-T | 30V～500V | 0～100A | 2 |
| 45 | BT500V200A-T | 30V～500V | 0～200A | 2 | |
| 46 | BT500V400A-T | 30V～500V | 0～400A | 1 | |
| 47 |
750V Series
|
BT750V100A-T | 40V～750V | 0～100A | 2 |
| 48 | BT750V200A-T | 40V～750V | 0～200A | 2 | |
| 49 | BT750V400A-T | 40V～750V | 0～400A | 1 | |
| 50 | 900V Series | BT900V200A-T | 40V～900V | 0～200A | 1 |
| 51 | 1200V Series | BT1200V100A-T | 50V～1200V | 0～100A | 1 |
